Worm Geared Motors

Worm Geared Motors
Send Inquiry
Product Code : 04
Brand Name : Atlas
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
  • Price
  • 4000 INR
  • Price Range
Product Description

Introduction
Amit Electricals  Worm Gear Motor Manufacturing in  "ATLAS" Make.Worm Gear Motor AERV And ARV series of our company produce. The Company has excellent technological strength and Advanced production facilities for manufacturing Worm Gear Motor. It capable of undertaking there full ranges of services from transmission system designs . Productions to after sales service there company is also committed to product reliability, durability and efficiency.

These Worm Gear Motors are made from very high quality raw material which ensures hassle free work performance at its user end. These Aluminium Geared Motors are technologically advanced and confirm to industrial quality norms of international standard. These Aluminium Gear Motors are widely finds its applications in various industrial sectors.

Worm Reduction Gear Motor

Range Ratio
We having Wide Range in Worm Gear Motor it Range Ratio 5, 10, 15, 20, 25, 30, 40, 50, 60, 80,100


Hp. Range
K W 0.1 KW to 5.5 KW.


Mounting

Worm Gear Motor with Universal Mounting so fitting with Any Direction Universal.

WORM
The worm Motor is Solid with shaft made of high grade alloy steel so as to give hard wear resisting surface duly case hardened & super finished. The Bearing & Oil Seal generals are accurately, cylindrically Ground to give smooth running.


WORM WHEEL
It is made of centrifugally cast phosphor Bronze rim shrunk and keyed on cast iron center block on bigger unit and solid casting for smaller units. GEAR HOUSING :It is made of close grain graded cast iron. Large cooling fins on both sides and adequate cooling area improves efficiency.

Out put Shaft
Made from high carbon steel to provide exceptional Strength & rigidity to minimize deflection. hollow shaft Gear box, solid shaft, both side shaft, one side Gear supply as per customer requirement.



Motor Mounting
ATLAS Make AERV series supply Flange Mounting Motor as per customer require hp in Single phase 220 volts +- 5%  50 Hz. +- 3% We are also able to Supply motor in 110 volts on HZ. 60 Also and Three phase 415, 380, 220, 48 volts +- 5% 3 phase 50 Hz. +- 3%



BEARING
The ball or roller bearings are used in worm wheel with ample capacity so that is can take journal and thrust loads.


Applications
Conveyors, Packaging, Loading, Automation, material handling lift.

Features
Excellent performance, simply structure, small cubage and high efficiency Easy to mount and maintain.

Wide output reduction ratio, large torque and good capability of enduring overloads

Running stably, low noise and wearing well Wide applicability and enough and safe dependability.
