        Force Cooling Motor

        Price 5999.0 INR/ Unit

        Get a Price/Quote
        MOQ : 1 Piece

        Force Cooling Motor Specification

        • Voltage
        • 220-440 Volt (v)
        • Product Type
        • Motor
        • Frequency (MHz)
        • 50-60 Hertz (HZ)
        • Protect Feature
        • Totally Enclosed
        • Phase
        • Three Phase
        • Warranty
        • 1 Year
        • Starting Type
        • Electric Start
        • Power
        • 0.075 to 55 Watt (w)
        • Color
        • Black & White


        Force Cooling Motor Trade Information

        • Minimum Order Quantity
        • 1 Piece
        • FOB Port
        • AHMEDBAD
        • Payment Terms
        • Cash in Advance (CID)
        • Supply Ability
        • 1000 Pieces Per Month
        • Delivery Time
        • 1 Days
        • Main Domestic Market
        • All India


        About Force Cooling Motor

        Company Name AMIT ELECTRICALS
        Brand Atlas
        Product Name Force Cooled Motor
        Operation Motor with force cooling for continuous operation in various industries
        Brake Type Not applicable (Focus on cooling mechanism)
        Range of Production Three Phase Force Cooled Motor
        Power: 0.10 to 75 HP (0.075 to 55 KW)
        Frame: 63 to 250M
        Poles: 2, 4, 6, 8, 10, 12
        Mounting Types Foot (B3)
        Flange (B5)
        Face (B14)
        Foot with Flange (B35)
        Foot with Face (B34)
        Frame Material Robust cast iron frame with integral feet
        Aluminum die-cast body available up to 100L frame (on request)
        Insulation Class F (Standard)
        Class H (on request)
        Ratings Continuous Duty (S1)
        Complies with performance standards
        Voltage & Frequency Standard: 415 -/+ 5%, 50 Hz -/+ 3%
        Optional: 220, 380, 460, 525 V at 50 or 60 Hz (on request)
        Protection IP44 (Standard)
        Optional: IP54, IP55 (on request)
        Shaft & Rotor Shaft: High carbon steel for exceptional strength & rigidity
        Rotor: High-pressure E.C. grade aluminum die-cast
        Dynamically balanced to reduce vibration & noise
        Bearings & Lubrication Bearings: C3 ball bearings
        Lubrication: Lithium-based grease (up to 150 deg C)
        Thermal Overload Protection Optional T.O.P. switch available on customer request
        Terminal Box Top position for Foot mounted (B3)
        Left/right positions available (on request)
        Earthing Terminals Minimum two: one in terminal box, one on foot
        Application Food processing industry
        Rolling mills
        Offshore applications
        Lifting machinery
        Textile machinery
        Geared motors
        Cable reeling drums
        Machine tools
        Features Highly efficient
        Durable
        Economical price
        Precision design
        Long life
        Noise-free
        Vibration-free
        Low running cost



        Force Cooling Motor
        Force Cooling Motor
        Force Cooling Motor
