Cooling Tower Motor 3.0 HP 2.2 KW 600 RPM

Send Inquiry

Request To Call Back

Cooling Tower Motor 3.0 HP 2.2 KW 600 RPM

Name: Cooling Tower Motor 3.0 HP 2.2 KW 600 RPM
Brand: AMIT ELECTRICALS
Price: 28000.0 INR
Availability: InStock

Price 28000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Cooling Tower Motor 3.0 HP 2.2 KW 600 RPM Specification

Sealed Type
Totally Enclosed Fan Cooled (TEFC)

Rated Frequency
50 Hz

Power Rating
2.2 KW

Horse Power
3.0 HP

Rated Voltage
415 V

Starting Type
Direct On Line (DOL)

Features
Heavy Duty, High Starting Torque, Low Vibration

Current Type
AC

Ambient Temperature
-15C to +40C

Torque
35 Nm approx.

Standard
IS:325, IEC60034

Noise Level
Below 75 dB

Efficacy
IE2/IE3 (as per request)

Poles Number
Other

Voltage
415 V

Bearing Type
Ball Bearing

Motor Type
Induction Motor

Cooling Method
Fan Cooled

Product Type
Low RPM Electric Motor

Output Power
2.2 KW

Protect Feature
IP54/IP55

Phase
Three Phase

Speed
600 RPM

Power
3.0 HP

Color
Grey

Weight
Approx 65-70 Kg

Shaft Diameter
38 mm

Mounting Type
Foot/Flange Mount (B3/B5/B14)

Lubrication
Grease Lubricated

Voltage Tolerance
10%

Connection
Star/Delta

Duty
S1 (Continuous)

Insulation Class
F/H

Application
Industrial Machines, Mixers, Gearboxes

Frame Size
132M

Service Factor
1.15

Altitude
Up to 1000 m above sea level

Frequency Tolerance
2%

Cooling Tower Motor 3.0 HP 2.2 KW 600 RPM Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
7 Days

About Cooling Tower Motor 3.0 HP 2.2 KW 600 RPM

Capitalise on the hot-selling Atlas Cooling Tower Motor from AMIT ELECTRICALS, crafted to deliver incomparable performance in industrial cooling tower fan operations. With a majestic 3.0 HP (2.2 KW) output at 600 RPM, this motor stands as the finest choice for demanding applications in highly humid environments. Engineered with a robust cast iron frame and stainless steel shaft, the IP55-protected, totally enclosed fan-cooled unit ensures reliability. Pick yours now for heavy-duty, continuous operation-ideal for textile, HVAC, and plastic industries.

Versatile Applications and Operational Guidance

The 3.0 HP 2.2 KW 600 RPM motor is not limited to cooling towers; its design supports a range of plant applications including mixers, gearboxes, and other industrial machinery. Installation is made easy with foot or flange mounting options (B3/B5/B14), and the connection can be set in Star/Delta configurations. Ensure regular lubrication and follow manufacturer directions for safe, optimal usage in continuous operations across various industrial setups.

Market Reach, Supply Reliability & Secure Transactions

This motor is highly valued in the domestic market, with AMIT ELECTRICALS ensuring secure shipping and reliable supply capabilities for bulk and repeat orders. Export and domestic customers benefit from flexible payment terms, advancing market value both locally and internationally. The product's strong export market presence and economical pricing establish it as a preferred choice among suppliers and traders seeking assured delivery and enduring service life.

Company Name	AMIT ELECTRICALS
Brand	Atlas
Product Name	Cooling Tower Motor
Application	Specifically designed for cooling tower fan operations in high humidity areas like industrial hvac, textile machinery, plastic machinery
Range of Production	Power: 0.25 to 25 HP (0.18 to 18.5 KW) Frame: 63 to 250M Poles: 4, 6, 8, 10, 12 Speeds: 1500, 1000, 750, 600, 500 RPM @ 50 Hz
Mounting Types	Flange (B5)
Frame Material	Robust cast iron frame
Ratings	S1: Continuous Duty
Voltage & Frequency	Standard: 415 5%, 3 Phase, 50 Hz 3% Optional: 220, 380, 460, 525 V at various frequencies
Protection	IP55 protection Suitable for up to 90% relative humidity
Shaft	Material: Stainless Steel AISI-410 Nut & Washer: Stainless Steel AISI-202 Extended shaft for fan fitting Corrosion protection
Insulation & Duty	Insulation Class F Designed for continuous operation (S1)
Bearings & Oil Seal	Double shielded bearings (ZZ or 2RS) Pre-lubricated with high temp grease Oil seal prevents moisture ingress
Enclosure	T.E.S.C. (Totally Enclosed Surface Cooled)
Thermal Overload Protection	Optional T.O.P. switch available on demand
Earthing Terminals	Minimum two: one in terminal box, one on body
Paint	Semi-glossy synthetic enamel (special paints available on request)
Features	Highly efficient Durable Smooth finishing Economical price Precision design Long life

FAQ's of 3.0 HP 2.2 KW 600 RPM:

Q: How does the Atlas Cooling Tower Motor enhance efficiency in industrial settings?

A: The Atlas Cooling Tower Motor is engineered for continuous heavy duty use, offering high starting torque, low vibration, and efficient operation at 600 RPM. This combination maximises energy use and delivers reliable cooling operations in demanding environments such as textile and HVAC plants.

Q: What applications besides cooling towers can this motor be used for?

A: In addition to cooling tower fan operations, this motor is suitable for mixers, gearboxes, and various industrial machines, making it a versatile solution for plant-wide applications requiring sturdy, continuous-duty motors.

Q: Where can the 3.0 HP 2.2 KW Cooling Tower Motor be supplied and installed?

A: This motor is available for supply across major domestic markets and also exported internationally. Installation is straightforward with foot or flange mounting options, suitable for various industrial plants, manufacturing facilities, and textile processing sites.

Q: What are the protection features included in this motor?

A: The motor offers IP54/IP55 protection, double-shielded bearings with high-temperature grease, oil seals to prevent moisture ingress, and is built with a robust cast iron frame for superior durability in high humidity and industrial environments.

Q: How can I ensure proper usage and a long service life for this motor?

A: To achieve long operational life, follow recommended installation routines, opt for scheduled lubrication, use suitable voltage as per specifications, and ensure that the motor operates within its rated environmental parameters. Optional thermal overload protection can be added for additional safety.

Q: What payment and shipping options are available?

A: AMIT ELECTRICALS provides secure payment terms, efficient supply ability for both bulk and repeat domestic and export orders, and ensures safe, secure shipping to your location for guaranteed market value.
