Cooling Tower Motor 2.0 HP 1.5 KW 500 RPM

Name: Cooling Tower Motor 2.0 HP 1.5 KW 500 RPM
Brand: AMIT ELECTRICALS
Price: 28900.0 INR
Availability: InStock

Price 28900.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Cooling Tower Motor 2.0 HP 1.5 KW 500 RPM Specification

Voltage
415V

Poles Number
Other

Current Type
AC

Cooling Method
IC411 (TEFC)

Rated Voltage
415V

Features
Rugged Construction, Vibration Free, Long Service Life

Starting Type
DOL (Direct On Line)

Sealed Type
Totally Enclosed

Ambient Temperature
-15C to 45C

Efficacy
IE2 / IE3 (as applicable)

Bearing Type
Ball Bearing

Torque
28.6 Nm (approx)

Horse Power
2 HP

Standard
IS 325 / IEC 60034

Rated Frequency
50 Hz

Noise Level
Less than 75 dB

Motor Type
Squirrel Cage Induction Motor

Power Rating
1.5 KW

Product Type
Electric Induction Motor

Output Power
1.5 KW

Frequency (MHz)
50 Hz

Protect Feature
IP55 Protection

Phase
Three Phase

Speed
500 RPM

Power
2.0 HP

Color
Grey

Dimension (L*W*H)
Standard as per model

Weight
Approx. 30-45 kg

Shaft Diameter
28 mm (approx)

Mounting Type
Foot / Flange Mounted

IP Rating
IP55

Non Drive End Bearing
6205 ZZ

Insulation Class
Class F

Cooling Fan Material
Plastic or Aluminium (as per model)

Altitude
Up to 1000m above sea level

Vibration Level
Within permissible limits as per IS/IEC

Operating Voltage Range
380-440V

Frame Size
112M

Drive End Bearing
6206 ZZ

Thermal Protection
PTC/RTD sensors on request

Duty Type
S1 (Continuous)

Painting
Anti-corrosive Epoxy Coating

Frequency Tolerance
+/- 5%

Cooling Tower Motor 2.0 HP 1.5 KW 500 RPM Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
7 Days

About Cooling Tower Motor 2.0 HP 1.5 KW 500 RPM

Unlock unparalleled efficiency with the Atlas Cooling Tower Motor by AMIT ELECTRICALS. Now available at an exclusive price cut, this 2.0 HP (1.5 KW) motor operates flawlessly at 500 RPM with Class F insulation and IP55 protection. Engineered for continuous-duty (S1) in highly humid environments, its rugged cast iron frame, anti-corrosive coatings, and stainless steel shaft ensure long service life and vibration-free performance. Ideal for industrial HVAC, textile, and plastic machinery, this motor guarantees terrific reliability and superior energy efficiency. Embrace quality, durability, and precision at unbeatable value.

Experience Flawless Power and Efficiency

Benefit from the advanced 2.0 HP, 1.5 KW, 500 RPM cooling tower motor offering robust performance and longevity. With special features such as double-shielded bearings, anti-corrosive epoxy painting, and IP55 protection, this motor is tailored for demanding environments. Its Direct On Line (DOL) starting method ensures ease of use while the extended stainless steel shaft is designed explicitly for seamless fan operation in cooling towers, ensuring consistent airflow in industrial applications.

Fast Sample Supply & Reliable Packaging

Express shipping is available for samples of the 2.0 HP, 1.5 KW, 500 RPM motor, allowing you to quickly assess its suitability. Each unit is supplied in sturdy, secure packaging for safe transit. Our sample policy covers standard chargeable rates, with detailed support on request. Rely on AMIT ELECTRICALS for prompt supply and dedicated after-sales service to meet your project demands efficiently and reliably.

Company Name	AMIT ELECTRICALS
Brand	Atlas
Product Name	Cooling Tower Motor
Application	Specifically designed for cooling tower fan operations in high humidity areas like industrial hvac, textile machinery, plastic machinery
Range of Production	Power: 0.25 to 25 HP (0.18 to 18.5 KW) Frame: 63 to 250M Poles: 4, 6, 8, 10, 12 Speeds: 1500, 1000, 750, 600, 500 RPM @ 50 Hz
Mounting Types	Flange (B5)
Frame Material	Robust cast iron frame
Ratings	S1: Continuous Duty
Voltage & Frequency	Standard: 415 5%, 3 Phase, 50 Hz 3% Optional: 220, 380, 460, 525 V at various frequencies
Protection	IP55 protection Suitable for up to 90% relative humidity
Shaft	Material: Stainless Steel AISI-410 Nut & Washer: Stainless Steel AISI-202 Extended shaft for fan fitting Corrosion protection
Insulation & Duty	Insulation Class F Designed for continuous operation (S1)
Bearings & Oil Seal	Double shielded bearings (ZZ or 2RS) Pre-lubricated with high temp grease Oil seal prevents moisture ingress
Enclosure	T.E.S.C. (Totally Enclosed Surface Cooled)
Thermal Overload Protection	Optional T.O.P. switch available on demand
Earthing Terminals	Minimum two: one in terminal box, one on body
Paint	Semi-glossy synthetic enamel (special paints available on request)
Features	Highly efficient Durable Smooth finishing Economical price Precision design Long life

FAQ's of 2.0 HP 1.5 KW 500 RPM:

Q: How does the Atlas Cooling Tower Motor ensure flawless operation in high-humidity environments?

A: The motor features double-sealed bearings, IP55 protection, and anti-corrosive coatings, making it highly durable and resistant to moisture, ensuring smooth performance in demanding, high-humidity industrial settings.

Q: What are the key benefits of the 2.0 HP, 1.5 KW, 500 RPM motor for industrial use?

A: This motor offers reliable continuous-duty operation (S1), robust cast iron framing, superior insulation (Class F), and efficient cooling, making it ideal for applications such as cooling towers, textile, and plastic machinery.

Q: Where can this motor be applied most effectively?

A: It is specifically designed for cooling tower fans but is also suitable for other industrial environments like HVAC systems, textile and plastic machinery where continuous, vibration-free, and efficient performance is critical.

Q: What special features make this motor unparalleled in its class?

A: Unique features include stainless steel shafts, advanced anti-corrosive epoxy painting, extended fan-fit shaft design, vibration-free construction, and IE2/IE3 efficiency, delivering flawless and long-lasting results.

Q: How can I get a sample of the 2.0 HP, 1.5 KW, 500 RPM motor, and what are the packaging details?

A: Samples are available upon request with express shipping. Each motor is securely packed using robust materials to ensure safe delivery. Standard sample charges apply, and our team can guide you through the process.
